Sawdust Wood Pellet Mill Alfalfa Crops Straw Bagasse Biomass Small Pellet Making Machine
Sawdust, sawdust, broken wood, straw, fruit shell, etc. have high water content, direct combustion, low thermal efficiency, incomplete combustion, and gasification of the water to take away a large amount of high-temperature heat energy, resulting in a large amount of smoke, increasing the cost of environmental protection and dust removal. The international general biomass utilization method is: biomass raw materials are crushed, dried, dehydrated, de-ashed, and formed under high pressure. The moisture content reaches 12-15%, the calorific value is 4000-4800kcal/kg, and the ash content is ≤1%. Fuel, saving transportation costs, efficient use, biomass pellet fuel production equipment is the main mechanical equipment.
Mikim biomass pellet fuel production equipment not only occupies the Chinese market (including Taiwan, Hong Kong, Macau), but also is exported to the United States, Germany, the United Kingdom, Switzerland, Russia, Morocco, Chile, Brazil, Thailand, Vietnam, Laos, Cambodia
The pellet machine using the die roll extrusion principle, the agriculture residues biomass raw materials processed into solid molding fuel, this will realize to continuous and stable production of industrialization. The processing route uses one-time drying, secondary crushing, continuous feeding, and adjust feeding mixed process combining, the Particle shaping fuel rate of 98%, bulk density, and particle density is high.
| Model | Power(kw) | Capacity(t/h) | Ring Model Diameter(mm) | Particle Size (mm) |
| JTMXCX350 | 55 | 0.7 | 350 | Φ2-Φ18 |
| JTMXCX400 | 75/90 | 1 | 400 | Φ2-Φ18 |
| JTMXCX420 | 90/110 | 1.3 | 420 | Φ2-Φ18 |
| JTMXCX508 | 110/132/160 | 1.8 | 508 | Φ2-Φ18 |
